# CAD Drawing Solutions
- [Home](https://www.extrememolding.com)»
- [Services](https://www.extrememolding.com/our-services)»
- CAD Drawing Solutions »
## Design for Manufacturability
Navigating your plastic or silicone injection molded product from prototype to production can sometimes be delayed by the need for computer-aided design (CAD) drawing files. Extreme Molding simplifies this process with trusted experts that we can refer you to for CAD drawing services, further ensuring seamless consultations and efficient product development.
## 2D & 3D CAD Model Solutions
When requesting a quote for an injection molding project, having a CAD drawing of your part is paramount. With these files, we can gain a better understanding of the size and shape of your product and can better advise you for a successful production run.
We've built relationships with trusted partners who help our clients turn their ideas into production-ready CAD drawings. By referring you to these companies, we can eliminate the delays of dealing with inexperienced vendors. To refer you to the right person, we'll just need:
- **Product Description:** Provide a detailed description of your product to ensure accurate representation in the CAD file.
- **Purpose of the Product:** Share insights into the function and application of your product.
- **Sample of Your Product:** If possible, sending a physical sample helps us capture intricate details accurately.
- **2D Drawing of Your Product:** While not a substitute for a CAD model, a 2D drawing can complement the information needed for the quote.
## What to Expect
Our commitment is to make the product development process as smooth as possible. With our CAD referral options, we strive for precision and efficiency in every step of the injection molding journey.
##### Are you ready to work with Extreme Molding? We hope so!
We can help you with your CAD file so you can move to production faster and with more confidence.
